No Touch Speed Face Miniac Plus
· Face Capacity: 3,000
· Card Capacity: 3,000
· Transaction Capacity: 3,000
· 5" Touch Screen Display
· 13.56MHz IC Card / Wi-Fi
· TCP/IP, Wi-Fi, Wiegand & RS-232
· Facial Recognition Speed: ≤1 Sec
· Linux-Based Operating System
· Size: 91.93 × 202.93 × 21.5 mm
| Brand | ZKTeco |
| Usage/Application | Attendance |
| Products Included | Adapter |
| Type Of System | Face Access Control |
| Display Type | Touch Screen, LCD |
| Interfaces | TCP/IP |
| Screen Size | 5 inch |
| Language | English |
| Installation Type | Wall Mounted |
| Connectivity Type | Wired |
| Power Source | Power Adapter |
· Visible Light Facial Recognition· Anti-spoofing algorithm against print attack(laser,color and B/W photos), videos attack and 3D mask attack Multiple Verfications: Face / Palm / Card / Password· Multiple card modules:125KHz ID card(EM) / 13.56MHz IC card (MF)· 3,000 face templates capacity
Recognition distance up to 2m long and extra wide angle recognition
The recognition distance has been greatly extended up to 2 meters long, which significantly improves maximum traffic rate. While most of algorithms only support 15-degree angle facial recognition,ZKTeco supports 30-degree angle facial recognition.
Specifications:
Display 5-inch Touch Screen
Face Capacity 3,000
Palm Capacity 1,500 (Optional)
Card Capacity 3,000
Transactions 150,000
Operation System Linux
Standard Functions ID Card, ADMS, T9 Input, DST, Camera, 9 digit user ID, Acess Levels, Groups, Holidays,Anti-passback, Record Query, Tamper Switch Alarm, Multiple Verify Modes
Hardware 900MHZ Dual Core CPU Memory 512MB RAM / 8G ROM 2MP WDR Low Light CameraAdjustable Light Brightness LED
Communication TCP/IP, WIFI(Optional), Wiegand input/output, RS485
Access Control Interface 3rd Party Electric Lock, Door Sensor, Exit Button, Alarm output, Auxiliary Input
Optional Functions 13.56MHz IC Card / WiFi
Face Recongntion Speed ≤1s
Biometrics Algorithms ZKFace VX5.8 / ZKPlam VX12.0
Power Supply 12V 3A
Working Humidity 10%-90%
Working Temperature -10 °C- 45 °C
Dimensios (W*H*D) 91.93*202.93*21.5mm
Supported Software ZKBioAccess
